X100PADS
Auto Key Programmer
X100PADS is an automotive key programming device with a 7-inch LCD display and Android 10 OS, which is designed for locksmiths, vehicle owners, and car mechanics. It supports vehicle programming for 2,000+ models under 60+ car manufacturers, providing solutions for reading immobilizer data, extracting PIN codes, adding keys, all keys lost, remote programming, etc. At the same time, X100PADS can also perform basic diagnostic functions like reading and clearing fault codes and checking vehicle live data in order to locate issues hidden inside vehicles. X100PADS also supports 30+ service functions to make maintenance a lot easier.
Description
-
● Locksmith-approved 7-inch engineering tablet
-
● Support key programming for most of the models on market
-
● Can match keys in both add key/all keys lost situations
-
● Comes with EEPROM Adapter as standard to help with module benchworks
-
● Read/Clear fault codes after programming process
-
● Contains 30+ special functions that helps with vehicle maintenance
Parameters
-
Operating System：Android 10
-
Processor：Quad-core processor 1.5GHz
-
Memory：2G RAM, 64G ROM
-
Display：7.0-inch touch screen with 1024×600 resolution
-
Communication Method：Wired
-
Connectivity：DB15 TO VGA, USB Type-C, WIFI 2.4/5G
-
Sensors：Gravity Accelerometer, Ambient Light Sensor
-
Auto Input/Output：Microphone, Speaker
-
Battery：2500mAh, 7.3V lithium-polymer battery
-
Working Voltage：9-36V
-
Operating Temperature：-10 to 40℃
-
Storage Temperature：-40 to 60℃
-
Humidity：<90%
-
Protocol compatibility：CANFD, DOIP
| SPECIAL FUNCTION--EEPROM | |
| SPECIAL FUNCTION--TPMS RESET | |
| SPECIAL FUNCTION--INSTRUMENT CLUSTER | |
| SPECIAL FUNCTION--AIRBAG RESET | |
| SPECIAL FUNCTION--Suspension Adaptation | |
| SPECIAL FUNCTION--DPF Regen | |
| SPECIAL FUNCTION--BMS Reset | |
| SPECIAL FUNCTION--Headlight | |
| SPECIAL FUNCTION--Throttle Adaptation | |
| SPECIAL FUNCTION--EPB Reset | |
| SPECIAL FUNCTION--EPS Adaptation | |
| SPECIAL FUNCTION--Oil Reset | |
| SPECIAL FUNCTION--Transport Mode | |
| SPECIAL FUNCTION--Tire Size Reset | |
| SPECIAL FUNCTION--Gearbox Adaptation | |
| SPECIAL FUNCTION--Seat Calibration | |
| SPECIAL FUNCTION--Injector Coding | |
| SPECIAL FUNCTION--Windows Initialization | |
| SPECIAL FUNCTION--CPS Reset | |
| SPECIAL FUNCTION--ABS Bleeding | |
| SPECIAL FUNCTION--Water Pump Actuation | |
| SPECIAL FUNCTION--TPMS RESET(EU) | |
| SPECIAL FUNCTION--Stop/Start Reset | |
| SPECIAL FUNCTION--AFR Adaptation | |
| SPECIAL FUNCTION--Power Balance | |
| SPECIAL FUNCTION--TPMSRESET(US) | |
| SPECIAL FUNCTION--TPMSRESET(JP) | |
| SPECIAL FUNCTION--TPMSRESET(KR) | |
| SPECIAL FUNCTION--TPMSRESET(AU) | |
| SPECIAL FUNCTION--Clutch Adaption | |
| SPECIAL FUNCTION--ABS/ESP Adaptation | |
| SPECIAL FUNCTION--EGR Relearn | |
| SPECIAL FUNCTION--FRM Reset | |
| SPECIAL FUNCTION--Write VIN | |
| SPECIAL FUNCTION--Turbo Relearn | |
| SPECIAL FUNCTION--A/C Relearn |
Accessories
- Color Carton
- Packing List
- Certificate of Quality
- Tool Case
- Quick Guide
Main Units
- Tablet
- EEPROM2 Adapter
- EEPROM PCBA
Packing List
- DB15 to VGA Main Cable
- USB3.0 Data Cable (Connect to PC)
- Charger for Tablet
- Power Cable US
- Power Cable EU
- Power Cable UK
Test Connectors
- OBD2-16
|
X100PADS
|
InPlus IK618E
|
X100PAD Elite2
|
|
|---|---|---|---|
Hardware |
|||
Processor |
Quad-core processor 1.5GHz |
Quad-core processor 1.5GHz |
Quad-core processor 1.5GHz |
OS |
Android 10.0 |
Android 10.0 |
Android 10.0 |
Storage (RAM+ROM) |
2+64G |
2+64G |
4+64G |
Display |
7 inch 1024*600 |
7 inch 1024*600 |
8 inch 1024*768 |
Camera |
8MP rear |
N |
8MP rear |
Connectivity |
USB Type-C
VGA |
USB Type-C
VGA |
USB Type-C |
Battery |
2500mAh, 7.2V |
2500mAh, 7.2V |
5000mAh, 7.3V |
WiFi |
Y |
Y |
Y |
Software |
|||
IMMO Functions |
Y |
Y |
Y |
OBD Key Programming |
Y |
Y |
Y |
EEPROM Modifications |
Y |
Y |
Y |
Bench programming |
N |
N |
Y |
Remote testing |
N |
N |
Y/ Need M600+603 |
VW 4/5/MQB |
Y/ Offline |
Y/ Offline |
Y/ Offline |
GM key programming w/ CAN FD |
Y/ Pin Required |
Y/ Pin Required |
Y/ Pin Required |
BMW CAS1-4/FEM&BDC
Ford Pincode Bypass |
Y |
Y |
Y |
Chrysler Pincode Bypass |
Y |
Y |
Y |
2018+ FCA SGW Bypass |
Y/ Cable Needed |
Y/ Cable Needed |
Y/ Cable Needed |
Read pin (Chrysler, VPW) |
Y |
Y |
Y |
Hyundai 4A key reading |
Y |
Y |
Y |
15-18 Land Rover/Jaguar key
programming via OBD |
Y/ KC501 |
Y/ Need KC501/M600 partly |
Y/ Need KC501/M600 partly |
Mercedes FBS3 AKL |
Y/ KC501 |
Y/ Need Adaptor+KC501 |
Y/ Need KC501/M600 |
BMW ECU replacement & Read ISN by bench |
N/ Partly |
N/ Partly |
Y/ Partly |
2019+ Nissan Sentra programming |
Y/ Cable needed |
Y/ Cable needed |
Y/ Cable needed |
VW Read PIN by bench & OBD |
Y/ Partly |
Y/ Partly |
Y/ Partly |
2018+ Toyota smart key AKL |
Y/ SK1 |
Y/ Need Anytoyo SK1 |
Y/ Need Anytoyo SK1 |
Renault Kwid/Logan programming |
Y |
Y |
Y |
Toyota 8A blade key AKL |
Y/ KC100,M822 |
Y/ Need Adaptor,KC100/KS-1 |
Y/ Need Adaptor,KC100/KS-1 |
2020 Ford PIN bypass |
Y |
Y |
Y |
Mitsubishi ID47 AKL |
Y |
Y |
Y |
Full system diagnosis |
Y/ Read+Clear DTC ,Live Data |
Y |
Y |
Service Resets |
36 |
36 |
34 |
Compatible Module |
|||
OBDI Connector |
Y |
Y |
N |
OBDII Connector |
Y |
Y |
Y |
EEPROM Adapter |
Y |
Y |
Y |
KC501 |
Optional |
Optional |
Optional |
KC100 |
Optional |
Y |
Y |
Warranty |
|||
Free Update |
2 YEARS |
3 YEARS |
2 YEARS |
Warranty |
2 YEARS |
2 YEARS |
2 YEARS |
